13.56MHz RF Plasma Power Source
Features:
Entry (input cable) has APFC modules to improve the input side power factor;
Use full digital control, high stability and high reliability;
High brightness LCD display, intuitive operation;
Perfect protection functions: overvoltage, overcurrent, over -temperature protection;
With continuous and pulse output mode;
Communication interface: default RS485, optional Ethercat, Ethernet, and CAN communication interface;
|
RLS330A-3K0/13-S2/4B*** |
3000W |
482.6×550.5×132.5 |
25kg |
Water cooling |
Technical parameters
|
Input |
AC input voltage |
220VAC±10% |
|
frequency |
50Hz |
|
|
Power factor |
≥0.98（100%RL） |
|
|
Output |
Rating output power |
3000W |
|
Output frequency |
13.56MHz±0.005%（25°C） |
|
|
Output impedance |
50Ω+j0 |
|
|
efficiency |
＞75%，Z=50Ω，FWD=额定 |
|
|
harmonic |
＜-45dB |
|
|
Bruise |
＜-50dB |
|
|
Pulse frequency |
100Hz~10KHz |
|
|
Pulse duty cycle |
10%~90% |
|
|
Output power stability |
＜300W±1% ＞300W±0.5% |
|
|
Export power adjustment range |
1%~ 100%rated power |
|
|
Power of glow |
10%~ 20%rated power (recommended) |
|
|
Output power leakage |
<1W, RF-ON set power = 0w ＜0.5W， RF-OFF |
|
|
Protection functions |
DC overvoltage |
DC voltage exceeds the set value protection, stopped |
|
DC over current |
DC current exceeds the set value protection, stopped |
|
|
DC overheating |
More than the setting alarm value protection, shutdown |
|
|
Portal over pressure |
The peak of the amplifier exceeds the set value protection, the stop |
|
|
Overheat |
More than the setting alarm value protection, shutdown |
|
|
External lock |
The external interconnection connector is not connected, the unit is stopped |
|
|
Inverse power overrun |
The reflex power exceeds the set threshold protection limit output power |
|
|
Operation environment |
Altitude |
Use more than 2000 meters to reduce it at the standard |
|
Operating temperature |
0 ～ + 40 ℃ |
|
|
humidity |
Humidity: 15 % ~ 85 % (no knot dew) |
|
|
Ventilation conditions |
good ventilate |
|
|
Cooling water temperature |
Temperature 20 ℃ ～ 30 ℃ |
|
|
Cooling water quality |
Pure water or ion water |
|
|
Water flow and pressure |
Flow ≥5L/min, pressure ≤ 0.5MPa, pressure difference ≥0.1 mPa |
